Chapter 5 - Section 1
NAVY PROJECTILES
25-mm Armor-Piercing Projectile
Fuzing: None.
Weight of projectile, filled: 8.88 ounces.
Length of projectile: 3.93 inches.
Length of assembled round: 8.74 inches.
Filling:
Tracer: Sodium nitrate, magnesium and barium peroxide.
Inert material: Kieselguhr (chiefly dry clay).
Weight of projectile fillings:
Inert material: 1.25 ounces (3.53 grams).
Tracer: 3.05 ounces (8.64 grams).
Color and markings: Black, white, or smoky blue over all.

Remarks: This projectile is listed in Japanese documents as armor-piercing, althrough the metal is softer that that used in smaller A.P. rounds.

Figure 362 – 25-mm Armor-Piercing Projectile.
