Chapter 4 – Section 1
ARMY PROJECTILES
Type 95 - 7-cm (70-mm) Armor-Piercing Projectile
Weight of complete round: 5.04 kg. (11.10 pounds).
Weight of projectile, fuzed: 4.45 kg. (9.80 pounds).
Weight of filling: 0.170 kg.

Filling: Preformed, paper-wrapped filling: Forward portion, "OSHIYAKU" (Picric Acid, 90 percent; paraffin, 10 percent; after portion, TNT).

Diameter at bourrelet: 70 mm (minus tol.).
Length of propellant case: 101 mm (4 inches).
Length of assembled round: 307 mm (12 1/16 inches).
Diameter of base of case: 81 mm (3 3/16 inches).
Width of rotating band: 10 mm.
Weapons in which used: Type 94 tank gun.
Fuzing: Type 95 small A.P. base fuze.
Propellant: 5 mm square grain (medium) 120 grams.

Figure 241 – Type 95 7-cm Armor-Piercing Projectile.
